CFP-40G-FR
Original price was: ₹5,100,000.00.₹1,020,000.00Current price is: ₹1,020,000.00.
- Product Description: CFP 40GBASE-FR optical transceiver module
- Manufacturer: Cisco
- Part Number: CFP-40G-FR
- Model Number: CFP-40G-FR - Cisco 40 Gigabit Optical Modules
- Model Description: CFP 40GBASE-FR optical transceiver module
- Rating:
- Product Can Be: Bought , Rented ,
- Availability: In Stock
- Also Available In: Refurbished
- Condition: New
- Warranty: New- 1 Year
Order Procedure
- Click on Get Quote button in the product page
- Provide Your Information
- Once your quote is received: Our expert will send you an email with our pricing and other information.
24/7 Online Service
USA- +1- 860-730-3336
UK- +1- 860-730-3336
India- +91-988-672-7317
Cisco CFP-40G-FR Overview
The Cisco CFP-40G-FR transceiver module is a high-performance, hot-swappable input/output device designed to connect seamlessly with 40 Gigabit Ethernet CFP ports on Cisco switches and routers. It delivers versatile and reliable 40G Ethernet connectivity for core and distribution layers in data center, enterprise, and service provider networks.
Quick Specifications
Product Code: CFP-40G-FR
Description: Cisco multirate 40GBASE-FR and OTU3 VSR2000-3R2 CFP Module for Single-Mode Fiber (SMF)
Dimensions: 144.8 x 82 x 13.6 mm
Wavelength: 1550 nm
Cable Type: Single-mode fiber (SMF)
Core Size: G.652
Cable Distance: Up to 2 km
Key Features
- Support for Industry Standards: Compatible with 40GBASE Ethernet and OTU3 standards, ensuring interoperability with IEEE and OTU3-compliant interfaces.
- Versatile Connectivity Options: Provides various interfaces for 40 Gigabit Ethernet and 10 Gigabit Ethernet applications.
- Pay-as-You-Populate Model: Optimizes cost-effectiveness by allowing gradual network upgrades.
- Digital Optical Monitoring (DOM): Enables real-time monitoring of optical signals for better network management.
- Cisco Quality Identification (ID) Feature: Ensures the module is certified and tested by Cisco, guaranteeing quality and reliability.
Applications
- Data Centers: Ideal for high-speed data transmission across core network layers.
- Enterprise Networks: Enhances connectivity in distributed networking environments.
- Service Provider Networks: Facilitates seamless integration in carrier-grade infrastructure.
CFP-40G-FR= Specification
CFP-40G-FR= Specification |
|
| Description | Cisco multirate 40GBASE-FR and OTU3 VSR2000-3R2 CFP Module for SMF |
| Dimensions | 144.8 x 82 x 13.6 mm |
|
CFP Port Cabling Specifications |
|
| Wavelength (nm) | 1550 |
| Cable Type | Single-mode fiber (SMF) |
| Core Size (microns) | G.652 |
| Modal Bandwidth (MHz-km) | \ |
| Cable Distance | 2km |
|
Optical Transmit and Receive Specifications |
|
| Type | 40GBASE-FR and OTU3 VSR2000-3R2 |
| Transmit Power (dBm)* | Max:3.0 per lane
Min:0.0 per lane |
| Receive Power (dBm)* | Max:3.0 per lane
Min:-6.0 per lane |
| Transmit and Receive Wavelength (nm) | 1530 to 1565 |
| * Transmit power and receive power are in average, unless specified. | |
|
Environmental Conditions and Power Requirements |
|
| Operating temperature | 0 to 70°C (32 to 158°F) |
| Storage temperature | -40 to 85°C (-40 to 185°F) |
| Power consumption | up to 8W per 40G CFP port |
