CPAK-100G-ER4L
Original price was: ₹7,917,936.15.₹1,583,587.23Current price is: ₹1,583,587.23.
- Product Description: CPAK module, 100G for applications <25km
- Manufacturer: Cisco
- Part Number: CPAK-100G-ER4L
- Model Number: CPAK-100G-ER4L - Cisco 100 Gigabit Optical Modules
- Model Description: CPAK module, 100G for applications <25km
- Rating:
- Product Can Be: Bought , Rented ,
- Availability: In Stock
- Also Available In: Refurbished
- Condition: New
- Warranty: New- 1 Year
Order Procedure
- Click on Get Quote button in the product page
- Provide Your Information
- Once your quote is received: Our expert will send you an email with our pricing and other information.
24/7 Online Service
USA- +1- 860-730-3336
UK- +1- 860-730-3336
India- +91-988-672-7317
Cisco CPAK-100G-ER4L Overview
The Cisco CPAK-100G-ER4L is a high-performance 100GBASE-ER4 Lite CPAK fiber module designed for Cisco switches and routers. It offers a compact, energy-efficient solution for long-distance connectivity over single-mode fiber (SMF). With a maximum reach of 25 km, this module is ideal for enterprise data centers, service provider edge networks, and telecommunication environments, ensuring scalability and reliable high-speed networking.
Key Specifications
| Attribute | Details |
|---|---|
| Product Code | CPAK-100G-ER4L |
| Description | 100GBASE-ER4 Lite Cisco CPAK Module for SMF |
| Dimensions | 11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in) |
| Wavelength (nm) | 1310 |
| Cable Type | SMF Duplex |
| Core Size | 9-micron core (per G.652 SMF) |
| Cable Distance | 25 km |
Features and Benefits
- High Bandwidth Support:
- Delivers up to 10 x 100-Gigabit Ethernet connections, offering 1 Tbps of front-panel bandwidth.
- Energy-Efficient Design:
- Consumes 40% less power compared to CFP2 and 70% less power than CFP modules, reducing operational costs.
- Space Optimization:
- Compact form factor enables 20% higher port density compared to competitors, maximizing infrastructure capabilities.
- Hot-Swappable Functionality:
- Easily replaceable CPAK modules ensure minimal downtime for critical operations.
- Interoperability:
- Compatible with IEEE-compliant standards, including 100GBASE-SR4, 100GBASE-LR4, 40GBASE-SR4, and 10GBASE-SR.
- Future-Proof Connectivity:
- Supports Cisco’s AnyPort solution, allowing seamless integration of 100G, 40G, and 10G modules, ensuring investment protection.
- Enhanced Monitoring and Security:
- Features Digital Optical Monitoring (DOM) for real-time performance tracking and Cisco quality ID for certified module verification.
Platform Compatibility
The Cisco CPAK-100G-ER4L is supported across a wide range of Cisco platforms, including:
- ASR 9000 Series Routers
- CRS-X Carrier Routing Systems
- Nexus 7000 and 7700 Series Switches
- NCS 2000, 4000, and 6000 Series Routers
- Cisco ONS Transport Platforms
Comparison with Similar Modules
| Parameter | CPAK-100G-ER4L | CPAK-100G-LR4= | CPAK-100G-SR4= |
|---|---|---|---|
| Description | 100GBASE-ER4 Lite for SMF | 100GBASE-LR4 for SMF (LC Connectors) | 100GBASE-SR4 for MMF |
| Cable Distance | 25 km | 10 km | 100 m |
| Wavelength (nm) | 1310 | 1310 | 850 |
| Cable Type | SMF Duplex | SMF Duplex | MMF |
| Power Consumption | Low | Low | Moderate |
Applications
- Enterprise and Service Provider Data Centers:
Efficiently connect multiple data centers over extended distances. - Telecommunications and Edge Networks:
Ensure reliable, high-speed transmission in service provider edge networks. - Scalable Networking:
Flexible deployment for enterprises requiring future-proof bandwidth solutions.
CPAK-100G-ER4L Specification
CPAK-100G-ER4L Specification |
|
| Description | 100GBASE-ER4 Lite Cisco CPAK Module for SMF |
| Dimensions | 11.6 x 34.8 x 101.2 mm (0.46 x 1.37 x 3.98 in) |
|
Cisco CPAK port cabling specifications |
|
| Wavelength (nm) | 1310 |
| Cable Type | SMF Duplex |
| Core Size (Microns) | 9-micron core SMF per G.652 |
| Modal Bandwidth (MHz*km) | \ |
| Cable Distance | 25 km |
|
Optical transmit and receive specifications |
|
| Type | 100GBASE-LR4 1310 nm SMF |
| Transmit Power | Max:+2.9 per lane
Min:-2.9 per lane |
| Receive Power (dBm) | Max:+4.5 per lane
Min:-14 per lane |
| Transmit and Receive Center Wavelength Range (nm) | Four lanes:
1294.53 to 1296.59 1299.02 to 1301.09 1303.54 to 1305.63 1308.09 to 1310.19 |
| Supported Mode | 1x100G |
| Supported Protocol | IEEE 802.3ba
ITU OTU4 |
|
Environmental conditions and power requirements |
|
| Storage temperature | -40 to 85° C (-40 to 185° F) |
| Operating temperature | 0 to 70° C (32 to 158° F) |
| Power consumption | At 70° C: <8.5 W maximum |
