CFP-100G-LR4
Original price was: ₹5,015,493.00.₹1,003,098.60Current price is: ₹1,003,098.60.
- Product Description: 100GBASE-LR4 CFP Module
- Manufacturer: Cisco
- Part Number: CFP-100G-LR4
- Model Number: 100GBASE-LR4 CFP Module
- Model Description: CFP-100G-LR4 - Cisco 100 Gigabit Optical Modules
- Rating:
- Product Can Be: Bought , Rented ,
- Availability: In Stock
- Also Available In: Refurbished
- Condition: New
- Warranty: New- 1 Year
Order Procedure
- Click on Get Quote button in the product page
- Provide Your Information
- Once your quote is received: Our expert will send you an email with our pricing and other information.
24/7 Online Service
USA- +1- 860-730-3336
UK- +1- 860-730-3336
India- +91-988-672-7317
CFP-100G-LR4 Overview
The Cisco 100GBASE CFP modules provide high-speed 100 Gigabit Ethernet connectivity, making them ideal for data center networking, enterprise core aggregation, and service provider transport applications.
Quick Specifications
The following table summarizes the key specifications:
Product Code: CFP-100G-LR4
Description: Cisco 100GBASE-LR4 CFP Module for Single-Mode Fiber (SMF)
Dimensions: 144.8 x 82 x 13.6 mm
Wavelength: 1310 nm band (LAN-WDM)
Fiber Type: Single-Mode Fiber (SMF)
Core Size: G.652 microns
Modal Bandwidth: Not applicable
Maximum Distance: 10 km
Digital Optical Monitoring (DOM): Supported
Product Highlights
The Cisco 100GBASE CFP Modules offer the following benefits:
- Supports 100GBASE Ethernet connectivity
- Hot-swappable design for easy integration into Ethernet CFP ports on Cisco switches and routers
- Flexible interface options for varied networking needs
- Pay-as-you-populate model for cost efficiency
- Integrated Digital Optical Monitoring (DOM) for performance tracking
- Cisco Quality Identification (ID) feature, ensuring compatibility with Cisco-certified and tested modules
Comparison with Similar Models
The table below compares the CFP-100G-LR4 with other Cisco CFP modules:
| Parameter | CFP-100G-ER4 | CFP-100G-LR4 | CFP-100G-SR10 |
|---|---|---|---|
| Description | Cisco 100GBASE-ER4 CFP Module for SMF | Cisco 100GBASE-LR4 CFP Module for SMF | Cisco 100GBASE-SR10 CFP Module for MMF |
| Dimensions | 144.8 x 82 x 13.6 mm | 144.8 x 82 x 13.6 mm | 144.8 x 82 x 13.6 mm |
| Wavelength (nm) | 1310 band (LAN-WDM) | 1310 band (LAN-WDM) | 850 |
| Fiber Type | SMF | SMF | MMF |
| Core Size (microns) | G.652 | G.652 | 50 |
| Modal Bandwidth (MHz-km) | Not applicable | Not applicable | 2000 (OM3) / 4700 (OM4) |
| Max Distance | 40 km | 10 km | 100 m / 150 m |
| DOM Support | Yes | Yes | Yes |
This comparison highlights the key differences between models, helping users choose the right module for their specific networking requirements.
CFP-100G-LR4 Specification
CFP-100G-LR4 Specification |
|
| Description | Cisco 100GBASE-LR4 CFP Module for SMF (<10 km) |
| Dimensions | 144.8 x 82 x 13.6 mm |
| Wavelength (nm) | 1310 band (LAN-WDM) |
| Fiber Type | SMF |
| Core Size (microns) | G.652 |
| Modal Bandwidth (MHz-km) | \ |
| Max Distance | 10 km |
| Digital Optical Monitoring (DOM) | Yes |
| Average Transmit Power (dBm) | Max:4.5 per lane
Min:-4.3 per lane |
| Average Receive Power (dBm) | Max:4.5 per lane
Min:-10.6 per lane |
| Transmit and Receive Wavelength | Four lanes, 1295.6 nm, 1300.1 nm, 1304.6 nm, and 1309.1 nm |
|
Environmental Conditions and Power Requirements |
|
| Operating temperature | 32 and 158°F (0 to 70°C) |
| Storage temperature | -40 to 185° F (-40 to 85° C) |
| Maximum power consumption | 24 W |
